Outsourced drafting for millwork shops

Shop drawings for architectural millwork.

Commercial, institutional and high-end residential. Microvellum drawings from your library, or complete AutoCAD shop drawings if your shop doesn't run Microvellum. Renderings when the job calls for them. Working remotely with shops nationwide.

Request a quote →
MicrovellumAutoCADSubmittalsShop drawingsEngineering
Sanctuary surround · plan, elevation, section D1 at 1-1/2" = 1'-0"
Up close

Every dimension, every callout

Base cabinet sections from a university research lab, shown near full size: drawer boxes, hardware, material tags and the dimensions a shop builds from.

University research lab · base cabinet sections at 1-1/2" = 1'-0", shown close to actual size
Selected drawings

Commercial, institutional, residential

Click any drawing to open it full size and zoom in.

CommercialSecurity desk · plan section at 3/4" = 1'-0", sections at 1-1/2" = 1'-0"
InstitutionalUniversity research lab · elevations at 3/4" = 1'-0"
CommercialMedical exam rooms · plans & elevations at 3/4" = 1'-0"
CommercialOffice build-out · shelving wall at 1" = 1'-0", details at 3" = 1'-0" and full size
InstitutionalTraining facility · plan & elevation at 1/2" = 1'-0"
ResidentialKitchen · refrigerator wall elevation at 1-1/2" = 1'-0"
ResidentialKitchen · 3D overview from the Microvellum model
Services

What I do for your shop

Drafting services

  • Submittal drawingsplans · elevations · sections
  • Shop drawingsfrom your Microvellum library
  • AutoCAD shop drawingsfor shops without Microvellum
  • Microvellum engineeringmachining & CNC output
  • AutoCAD detailssteel · solid wood
  • DeliverablesPDF submittals · DWG · Microvellum project files

Project types

  • Commercialmedical · offices · hospitality · venues
  • Institutionaluniversities · labs · schools · public facilities
  • High-end residentialkitchens · libraries · closets · built-ins
Rendering

Renderings from the same model

Photoreal views built from the Microvellum model behind the shop drawings, for client approvals and design reviews.

Kitchen render with painted island and checkered floor Kitchen island with marble top and turned legs Kitchen with oak cabinetry and timber ceiling beams High-rise kitchen with walnut wall cabinets and white island
How a job runs

From architectural set to submittal-ready drawings

  1. Send the set

    Architectural drawings plus a sample of your shop's drawings or standards.

  2. Get a quote

    Fixed price and turnaround, based on sheet count and scope.

  3. Drafting

    Drawn in Microvellum from your library, or in AutoCAD to your shop's standards, so the output matches your shop.

  4. Your approval

    In-house revisions are included until you approve the set to send to your client. Revisions after that are quoted separately.

Contact

Have a set ready to quote?

Email the architectural set, or a link to it, with the project type and due date. I'll reply with questions or a quote.

I'm Richard McCrary, an architectural millwork and casework drafter in Wake Forest, NC. I've been drawing for millwork shops since 2019, and every job is drafted by me, start to finish.

Email for a quote info@richardmccrary.com
